DJF Series 5kW vs. 10kW High-Power IP Systems: A Comprehensive Comparison for Geological Exploration

1. Core Technical Specifications Comparison

Key Parameters	DJF-5kW System	DJF-10kW System
Max Transmit Power	5 kW	10 kW
Max Transmit Current	6 A	10 A
Exploration Depth	500–800 m	800–1200 m
Rectifier Weight	57 kg	80 kg
Current Storage Capacity	8,000 datasets	100,000+ datasets
Synchronization Accuracy	0.1 ppm quartz clock	Dual-mode (GPS + quartz)
Extreme Environment	-20°C to 60°C	Enhanced cooling design

---

​2. Product Advantages

DJF-5kW System Highlights:

1. ​Lightweight Design: 28% lighter than 10kW system (rectifier 40% lighter), ideal for rugged terrains.
2. ​Cost-Effective: 35% lower upfront cost for 500m-level exploration.
3. ​Flexible Storage: 16GB standard (expandable to 64GB) for mid-sized projects.

DJF-10kW System Highlights:

1. ​Deep Exploration: 1200V/10A output enables 1200m+ subsurface detection.
2. ​Industrial Reliability: 40% longer continuous operation with smart thermal control.
3. ​Big Data Support: Military-grade flash storage for large 3D surveys.

---

​3. Application Scenarios

DJF-5kW Recommended Uses:

• Medium-scale metal ore prospecting (Cu/Pb-Zn/Au).
• Urban underground space mapping (pipelines/subways).
• Hydrogeological surveys (shallow geothermal/underground rivers).
• Emergency geological assessments (landslide evaluations).

DJF-10kW Recommended Uses:

• Deep-seated orebody exploration (porphyry Cu/deep Au).
• Shale gas/hot dry rock resource evaluation.
• Critical infrastructure bedrock analysis (nuclear plants/bridges).
• Military deep-structure geological mapping.

---

​4. Configuration Recommendations

Basic Survey Kit (5M RMB Budget):

• 2×5kW transmitters + 4×receivers + portable rectifier.
• Ideal for provincial geological surveys.
• Advantage: 3-vehicle transport, 3–5 km daily coverage.

Deep Exploration Kit (12M RMB Budget):

• 4×10kW transmitters + 6×high-precision receivers + industrial rectifier array.
• For national-level deep mineral exploration.
• Advantage: 2,000 data points/day with data processing workstation.

---

​5. Technological Evolution

Technology	5kW System	10kW System Innovations
Noise Immunity	128-level AGC	Adaptive filtering + dynamic noise reduction
Data Integrity	IP67 + power-loss protection	Dual-storage redundancy + CRC
Sync Precision	±1 ms error	GPS-disciplined clock (±0.01 ms)
Power Strategy	Fixed-cycle	Smart pulse-width modulation

Explore Revolutionary GIM Series Now

Visit Product Page Now ：
DJF Series 5kW
DJF Series 10kW
Whether you’re engaged in environmental monitoring, mineral exploration, or urban underground space development, the DJF Series High-Power Digital DC Induced Polarization Measurement System. Our product page features:

• Technical comparisons of full series (DJF Series 5kW/DJF Series 10kW)
• Typical engineering configuration packages
• Global case study video demonstrations
